TP-LINK TL-SG1008D 8-Port Gigabit Desktop Switch
SPECIFICATION
|
HARDWARE FEATURES |
|
|
Standards and Protocols |
IEEE 802.3i/802.3u/802.3ab/802.3x |
|
Interface |
8 10/100/1000Mbps RJ45 Ports |
|
AUTO Negotiation/AUTO MDI/MDIX |
|
|
Fan Quantity |
Fanless |
|
Physical Security Lock |
No |
|
Power Consumption |
Maximum: 4.63W (220V/50Hz) |
|
External Power Supply |
External Power Adapter (Output: 5VDC / 0.6A) |
|
Jumbo Frame |
15 KB |
|
Switching Capacity |
16 Gbps |
|
Dimensions (W x D x H) |
7.1 * 3.5 * 1.0 in. (180 * 90 * 25.5 mm) |
|
Max Power Consumption |
4.63W (220V/50Hz) |
|
Max Heat Dissipation |
15.80BTU/h |
|
SOFTWARE FEATURES |
|
|
Transfer Method |
Store and Forward |
|
MAC Address Table |
4K |
|
Advanced Functions |
Green Technology, saving power up to 80% |
|
802.3X Flow Control, Back Pressure |
|
|
OTHERS |
|
|
Certification |
FCC, CE, RoHs |
|
Package Contents |
8-Port Gigabit Desktop Switch TL-SG1008D |
|
Power Adapter |
|
|
Installation Guide |
|
|
System Requirements |
- |
|
Environment |
Operating Temperature: 0°C104°F) |
|
Storage Temperature: -40°C158°F) |
|
|
Operating Humidity: 10%~90% non-condensing |
|
|
Storage Humidity: 5%~90% non-condensing |
