General Specifications

DAB tuning range

174.928 MHz – 239.200 MHz (Band-III)

FM tuning range

87.5 MHz – 108 MHz (varies by countries)

Transducer

2 x 1.5” (full range)

Rated output power

2 x 5 W RMS

Power supply

100 - 240V AC, ~50/60Hz

Frequency response

65 Hz – 20 kHz (-6dB)

Signal-to-noise ratio

> 80 dB

Backup battery

210 mAh CR2032

Dimensions

Product dimensions (W x H x D)

209 x 137 x 83 mm / 8.2'' x 5.4'' x 3.3''

Product weight

0.78 kg / 1.73 lbs

Packaging dimensions (W x H x D)

225 x 142 x 160 mm / 8.9'' x 5.6'' x 6.3''

Packaging weight

1.36 kg / 3.00 lbs

Control and Connection Specifications

USB charge out

5 V 3 A (maximum)

USB port

USB-C

Bluetooth® version

5.3

Bluetooth® profile

A2DP V1.4, AVRCP V1.6

Bluetooth® transmitter frequency range

2.400 – 2.4835 GHz

Bluetooth® transmitter power

≤ 10 dBm (EIRP)

Bluetooth® transmitter modulation

GFSK, π/4 DQPSK, 8DPSK

What's in the box

- 1 x JBL Horizon 3
- Power cord (up to 4 pcs depending on region SKUs)
- 1 x Pig-tail antenna
- 1 x Quick start guide
- 1 x Safety instruction and warranty card
